FORMART 2 Smart Vacuum Former

Featured

Sorry, this product is not available to purchase in your country.

FORMART 2 Smart Vacuum Former

NT$64,890

Accessories included:

  • 50cm x 30cm HIPS * 30 sheets
  • One set of cat bowl molds
  • Plastic sheet size switching kit
  • Webbing remover kit
  • USB  cable
  • Heat-resistant gloves
  • Basic tool kit

**L/T is around 2 weeks**

SKU: MY171MA110 Category:

Description

FORMART-小型真空成型機(桌上型真空吸塑機)小型真空成型機自造者桌面

FORMART 2 Main Features



  • Built-in industrial-grade vacuum pumps, combined with intelligent control, allows you to precisely adjust the vacuum pressure without letting go of any creative details.
  • "Advanced Mode" gives you maximum flexibility for professional use, while the "Simple Mode" has three built-in smart modules to get you started quickly.
  • Complete material database makes it easy to create, regardless of whether the original plastic sheet is used or not.
  • Industrial grade quartz heating tube, heating speed is 3 times faster than others! The heater provides excellent temperature uniformity and achieves best forming quality.
  • Exclusive preheating process, greatly improving the success rate
  • Built-in dehumidification function, which can automatically control the dehumidification parameters for different materials of the sheets.
「FORMART fills the gap between prototype and mass production, and its smooth operation makes the development process much easier.
Both the production and start-up companies should invest in one.
。」 - ATOM 3DP Founder Lawrence Lee
「Intelligent operation system not only greatly improves the yield rate, but also transforms the complicated vacuum forming into a convenient tool that can be easily used.
In addition, the variety of materials used and the recyclability make the equipment more flexible.」- IFSFXartmaker Founder- Victor Chang



FORMART 2 Exclusive



Plastic sheet auto-detection & alert speaker

With a complete database of plastic sheets and the world's only plastic sheet detect sensor, you can set the working parameters instantly while loading the sheet. There is even a built-in high quality speaker to alert you when the heating is complete, making it a great convenience for professional use.

Largest forming area & 4 size switchable

With 47cm x 27cm largest forming area on the market, and a unique 4-size switch function, you can choose the most suitable size of plastic sheet according to the size of your work, so that every inch of your plastic sheet does not have to be wasted!

Speed cooling & automatic mold releasing

Built-in dual brushless fans help to cool down your blister quickly, and the reversing valve can automatically reverse the air blowing, allowing you to remove the mold more easily and mass produce your work more efficiently.

FORMART unboxing

Specification



  • Machine Size:625(W) x 534(H) x 476(D)mm
  • Weight:25Kg
  • Power: 100-120VAC@1500W or 220-240VAC@1700Watt
  • Display:3.5” 480*320 full color LCD
  • Heater:Quartz heater tube
  • Heating Temperature:90~230゚C
  • Sheet Size:500×300mm;420×300mm(A3) / 300×300mm;300×205mm(A4)
  • Sheet Thickness:0.3~3.0mm
  • Pump type:DC brushless pump *1、AC induction pump*1
  • Pressure Range:-10~-90KPA(Tunable)
  • Max. of Draw:160mm

Additional information

Weight 35 kg
Dimensions 67 × 50 × 59 cm
