💡Popular Applications
FORMOVA Smart Vacuum Former is designed for a wide range of applications. Traditional tooling often requires expensive molds, high minimum order quantities, long lead times, and significant storage space. With FORMOVA, you can create prototypes, custom packaging, and low-volume production parts anytime, anywhere—quickly and cost-effectively.
Cosplay Armor
Custom Trays
Blister Packaging
RC Car Bodies
Dessert Molds
STEAM Education
Sign Making
Motorcycle Fairings
Why Does FORMOVA Use an Upward Mold-Lifting Design?
FORMOVA features an upward mold-lifting design that raises the mold into the heated plastic sheet. This approach keeps the material evenly stretched before forming, reducing sagging caused by gravity and producing more uniform wall thickness with sharper details—especially on large parts.
Compared with conventional downward-forming systems, the upward mold-lifting structure provides better material control for large-format and deep-draw vacuum forming. The result is higher forming accuracy, less material waste, improved repeatability, and more reliable production for product development, prototyping, and low-volume manufacturing.
Engineered for Consistent Professional Vacuum Forming
Every detail matters. FORMOVA combines precision control and intelligent sheet leveling to deliver consistent, high-quality vacuum forming results every time.
⭐️ Large Forming Area
With a spacious 57 × 42 cm forming area, FORMOVA is ideal for industrial prototyping, model making, custom trays, blister packaging, and low-volume manufacturing.
⭐️ Precision Multi-Zone Heating
Equipped with an infrared temperature sensor and four independently controlled heating zones, FORMOVA delivers even heat distribution across the plastic sheet for improved vacuum forming quality, accuracy, and process consistency.
⭐️ Smart Material Database
Preloaded with 17 material profiles and supporting 5 custom presets, FORMOVA lets you select the optimal settings without extensive material expertise, making vacuum forming faster, easier, and more consistent.
⭐️ Pre-Stretch Technology
Uneven wall thickness in blister packaging? FORMOVA's built-in pre-stretch function expands the heated plastic sheet before forming, improving material distribution for more uniform wall thickness and consistently higher-quality finished parts.
Professional Vacuum Forming, Perfected
Enhanced Clamping, Vacuum Control, Demolding, and Mold Locking
⭐️ World's First Pneumatic Sheet Clamping System
FORMOVA features a unique two-stage pneumatic sheet clamping system with a two-hand safety operation, reducing the risk of pinch injuries while providing faster, more secure, and more reliable sheet clamping.
⭐️ 6° Forward-Tilt Forming Platform
The 6° forward-tilted forming platform provides easier mold placement, more accurate sheet positioning, and improved visibility throughout the forming process, creating a more efficient and ergonomic workflow.
⭐️ Built-in Positive Pressure Mold Release
FORMOVA features a built-in positive pressure system, eliminating the need for an external air supply. With the push of a button, positive air pressure assists mold release, making it faster and easier to remove blister packaging, custom trays, and formed parts.
⭐️ High-Performance Vacuum Pump
FORMOVA is equipped with a powerful 750 W vacuum pump, delivering up to −93 kPa of vacuum pressure. Based on its 57 × 42 cm forming area, the system generates a theoretical holding force of approximately 2.5 tons—roughly equivalent to the weight of a Tesla Model X. 🚗💨
*Calculated using a 57 × 42 cm forming area at −93 kPa, resulting in a theoretical holding force of approximately 2.5 tons.
The intelligent vacuum control system allows users to adjust vacuum pressure continuously from −10 kPa to −93 kPa.
⭐️ Integrated Mold Locking System
The forming platform features integrated mold mounting points that securely lock molds in place. Combined with the built-in positive pressure mold release system, it improves stability and efficiency for repeated forming and low-volume production.
⚙️ Specifications
Key Features
Heater fully extended: 112 (D) cm
Allow Clearance for Heater Extension
📝 Request a Quote
